- Compliance with DIN 12576 / Drip Tip
- Interchangeable Inner & Outer Joints
- Made From Heat Resistant, Low Expansion
3.3 Borosilicate Glass
| Cat. No. | Ground Joint (Socket) | Ground Joint (Cone) | Effective Length (mm) | Connector | Pack of |
|---|---|---|---|---|---|
| CO.12.01 | 14/23 | 14/23 | 150 | Screw Thread | 1 |
| CO.12.02 | 19/26 | 19/26 | 200 | Screw Thread | 1 |
| CO.12.03 | 24/29 | 19/26 | 200 | Screw Thread | 1 |
| CO.12.04 | 19/26 | 24/29 | 300 | Screw Thread | 1 |
| CO.12.05 | 24/29 | 24/29 | 300 | Screw Thread | 1 |
| CO.12.06 | 19/26 | 19/26 | 350 | Screw Thread | 1 |
| CO.12.07 | 24/29 | 24/29 | 350 | Screw Thread | 1 |
| CO.12.08 | 19/26 | 19/26 | 400 | Screw Thread | 1 |
| CO.12.09 | 24/29 | 24/29 | 400 | Screw Thread | 1 |
| CO.12.10 | 24/29 | 24/29 | 500 | Screw Thread | 1 |
| CO.12.11 | 24/29 | 24/29 | 600 | Screw Thread | 1 |
| CO.12.12 | 24/29 | 24/29 | 750 | Screw Thread | 1 |
| CO.12.13 | 34/35 | 24/29 | 500 | Screw Thread | 1 |
| CO.12.14 | 34/35 | 29/32 | 600 | Screw Thread | 1 |
| CO.12.15 | 34/35 | 24/29 | 750 | Screw Thread | 1 |
| CO.12.16 | 34/35 | 29/32 | 900 | Screw Thread | 1 |
| CO.12.17 | – | 24/29 | 300 | Screw Thread | 1 |
| CO.12.18 | – | 29/32 | 350 | Screw Thread | 1 |
| CO.12.19 | – | 24/29 | 250 | Screw Thread | 1 |
| CO.12.20 | 29/32 | 29/32 | 250 | Screw Thread | 1 |
| CO.12.21 | 29/32 | 29/32 | 400 | Screw Thread | 1 |
